Estimate your profit from Protected Farming
Polyhouse or a Greenhouse is a house or a structure made of translucent material like polyethylene, where the plants grow and develop under controlled climatic conditions. The size of structure can differ from small shacks to big-size buildings as per the need.
Agriplast Protected Cultivation supplies the best designed structures in the market. We design our structures as per Israeli designs and take pride in being associated with one of the biggest names in the industry. We offer best grade of Polyhouse and self-sustaining protected structures. These products are manufactured with world standard quality norms, top quality components and modern methods.
|FEATURES||AGRIPLAST ISRAELI DESIGN POLYHOUSE|
|Height of structure||6.8 TO 7 meters from ground level|
|Side ventilation||4 meters which provides total ventilation of 48% which is best in its segment.|
|TOP VENT||1.2 meters|
|Pipe quality and Galvanization||375 to 400 GSM|
|Nut bolts and Connectors||22-micron zinc ferrous coated. Main connectors are 5 mm coated (Zinc coating).|
|Foundation||76 mm dia with 2 mm thickness. Crimped foundation which gives more strength.|
|Door||Aluminum double sliding door|
|Gutter thickness||1.6 mm Galvanized gutters with trapezoidal shape.|
|End gutters||We provide gutters at both the end of the structure giving extra surface area for water harvesting.|
|Shade net mechanism||Pulley system hybrid mechanism. The shade net moves with thousands of pulleys and sandwich clips which is well designed for easy movement without tearing the Shade net. Results in hassle free operations for many years.|
|Reinforcement and Anti wind breakers||We provide multiple reinforcement and anti-wind breakers for the strength of the structure.|
|Hockey pipe||Square pipe is given. Square pipe provides more stability to the structure due to more surface area.|
|Tonnage of structure||20- 21 tones of steel. Total structure weight is 24 tones approx. depending on the structure size.|
|Profile||Aluminum profile. Heat doesn’t transfer resulting in better plastic life.|
|Spring||PVC coated spring IMPORTED. Doesn’t heats the plastic.|
|PVC Wires for Shade net Mechanism||PVC wires used for shade net moving without wear and tear.|
|Shade net / Insect net||Agriplast make|
|Multiple designed connectors||Multiple Israeli designed connectors are used for better strengths for the structure. This is one of the key USP of our structure.|
|AI Automation system||Our polyhouse comes with AI climate control which provide full control to the user for the automatic operation of polyhouse.|
|Screen Automation||We use imported Italian products for screen and side vent automations for long term hassle free operations.|
|Other Features||On special request we can provide Curtain box system/Aluminet shadenet which last for more than 20 years with warranty of 5 years by Ginegar & we also provide FLC mechanism for easy movement of the side vents.|
|Agronomist Support||We give free of cost agronomist support to all our farmers for assured success.|
ROBUST & RELIABLE
High Quality Components
Gi-pipes of more than 350 GSM, Higher structure of up to 7m to 8m, Gutter height ranges from 4m to 5m, Top ventilation of 1.2m to 1.3m & Connector thickness from 2mm to 5mm (with electro galvanizing up to 20 microns).
Second Layer Mechanism
Rope system, Manual screen movement with chain pulley, Motorized screen movement with GI wire rope mechanism, Motorized rack and pinion system & Motorized with automation and temperature control sensors.
a) Anti-flap side curtain box and to cover the partition, Normal pipe rollup curtain assembly, Chain rollup curtain mechanism, Motorized curtain mechanism, Motorized curtain mechanism & Anti Hail reinforcement system above the Polyhouse structure.
Nothing touches people more than a true story of struggle and success. A story that reflects real accomplishments that others can relate to and learn from. Producers around the world face very similar challenges. Given the opportunity to share them, they can not only help other farmers but also help strengthen their communities and the global environment.
Agriplast Agripreneurs created history in Polyhouse Farming not only in India but also in other countries.
OUR WORK METHODOLOGY
Call Agriplast Customer Support and Tell us your requirements.
Our Expert will analyse growing conditions and Develop a plan.
Quotation Approval Process and Start Manufacturing Components.
Materials Delivered and Our team will initiate installation Process.
